Wall Mounted Eye & Face Wash, With Bowl & Foot Treadle

Wall Mounted Eye & Face Wash, With Bowl & Foot Treadle

The Portable Gravity Fed Eye Wash Unit is a critical safety device designed for emergency eye irrigation in workplaces where eye hazards are present. Its self-contained, gravity-fed design allows for immediate and gentle eye flushing, helping to minimise eye damage in the event of an eye exposure incident.

Features

• AEROSTREAM technology delivers a gentle cascade of soft flow water to flush away any hazardous materials from the eyes and face.
• SWIRLTECH technology delivers a precise pattern and controlled flow rate of a large volume of flushing fluid, ensuring optimum decontamination when it is needed most.
• FCR/FCA all showers and eye washes come standard with Flow Control Regulators and/or Flow Control Adjuster.
• The shower FCR assists for simultaneous flow between the shower and eyewash to ensure minimum flow outputs are not compromised.
• The eyewash incorporates our FCA, allowing for the fine-tuning of flow output.
• Eyewash pipework and fittings are 304SS
• Stainless Steel Eye Wash Bowl
• Hand and Foot Operated via Push Handle and Foot Treadle
• ABS Eye/Face Wash Nozzle Assembly
• Technical Information for the Wall Mounted Eye & Face Wash, With Bowl & Foot Treadle
• INLET CONNECTION - 15mm BSPF
• WATER SUPPLY-LINE SIZE - 15mm *Must be hydraulically sized to meet requirements
• OUTLET CONNECTION - 32mm BSPF
• MINIMUM PERFORMANCE REQUIREMENTS - 210kPa / 30PSI *Caution should be taken when pressure exceeds 550 kPa
• FLOW OUTPUT (AT MIN PERFORMANCE REQUIREMENT) - Shower: 80 LPM Eye Wash: 15 LPM Eye-Face Wash: 30 LPM
• WEIGHT(KG) - 5
• DIMENSIONS(CM) - 61 X 33 X 46
